The superior solution for energy retrieval, “green lifting” and optimal productivity. Constant battery recharging becomes a thing of the past.
The 8.5t, 10.0t & 13.0t EARTHLIFTS from Stertil-Koni are the first hydraulic “green” mobile lifting columns in the industry. The environmentally-friendly, wireless mobile column lifting solution for all of your heavy-duty lifting needs.
Download brochure| Model | ST 1085 - 8.5t | ST 1100 - 10.0t | ST 1130 - 13.0t |
|---|---|---|---|
| Lifting Capacity | 8,500 kg | 10,000 kg | 13,000 kg |
| Lifting Height | Maximum 1,850 mm | Maximum 1,850 mm | Maximum 1,850 mm |
| Lifting time | 94 seconds | 94 seconds | 94 seconds |
| Fork Type | Adjustable | Adjustable | Fixed |
| Fork Length | 350 mm | 300 mm | 620 mm |
| Fork Width | 240 - 560 mm | 240 - 560 mm | 1006 mm |
| BROCHURE | BROCHURE | BROCHURE |
The Stertil-Koni EARTHLIFT column lift, uses the patented Stertil-Koni Active Energy Retrieval System. This provides you with an ecological mobile wireless lifting solution for all of your heavy duty lifting requirements.
The EARTHLIFT can achieve up to 50 lifting cycles without battery charging. This creates optimum productivity in the workshop. No more expensive downtime because of waiting for batteries to charge.
The principle of the Active Energy Retrieval System (AERS) is as brilliant as it is simple: to use the energy generated by the raised vehicle as it comes back down. In other words: regain the gravitational energy.
The revolutionary ebright smart control system combines intuitive ease of use with maximum visual information about the lifting process.
The 7” full colour high resolution touch screen is also operational when wearing gloves. With the user ID key, the user can configure the system to their personal needs.
| Touch Screen |  |
Totally cable-free, Stertil-Koni EARTHLIFT eliminates potentially expensive repair bills of damaged cables and offers ultimate safe working conditions, as there are no tripping hazards caused by cables all over the workshop floor.
| Overload Protection |  |
| Unique Synchronisation System |  |
Independent mechanical gravity-operated locking pawl starts at 125mm from floor level. Minimal incremental locking profile with 35mm increments, the smallest available in the industry. Vehicle damage prevention due to 250mm distance between lift and vehicle. Precision synchronisation starts at 15mm height difference between the individual lifts
Individual user settings for choosing language and units. Protection against unauthorised use with personalised ID key. Visual display of maximum programmable lifting height
To guarantee maximum safety in the workshop, the Stertil-Koni products have received the required certifications.
The total lifting capacity is variable by linking multiple lifting columns together. A maximum of 32 columns can be linked in a single configuration allowing virtually every vehicle or combinations to be lifted.
The unique synchronisation system creates a smooth lifting and lowering cycle, even in the event of an extremely uneven load distribution. With the adjustable lifting forks virtually all wheel diameters can be lifted, without the need for small wheel adaptors.
